Products

Model

SX3255MT384

Drive type

6x4 LHD

Cab

Type

H3000 mid-lengthened flat roof with 1 sleeper

Equipment

Hydraulic main seat, four-point hydraulic suspension cab, lever-type rear-view mirror, electric air conditioner, electric window shaker, manual flip, telescopic shaft control, ordinary air filter, metal bumper, two-stage pedal, water tank protection grid, tail light Protection grid, 165Ah maintenance-free battery, full English logo

Vehicle Main
Dimensions

Wheel base(mm)

3775+1400

Total dimensions

8750×2490×3450

Weight

Kerb mass

12400kg

Total mass

25000kg

Engine

Brand

WEICHAI

Model

WP10.380E22

Power(kw/HP)

279/380

Displacement(L)

9.726

Emission  Standard

Euro II

Transmission

Brand

FAST

Model

10JSD180+QH50

Control type

Manual

Gear shift

10-forward and 2-reserve speeds

axle

Front axel

MAN 9.5T

Rear axel

16T Man double reduction axle with ratio 5.92

Tires

Type(Standard)

12.00R20

Dump Body

Cargo Dimension (mm)

5600×2300×1500, middle lifting system, thickness of floor 8mm and side 6mm
