SHACMAN X3000 8×4 375HP Dump Truck Overview

The SHACMAN X3000 8×4 dump truck is a heavy-duty tipper truck designed for transporting bulk materials at construction sites, mines, quarries and infrastructure projects.


Its 8×4 configuration is suitable for applications that require a multi-axle heavy-duty truck. The 375HP engine provides the stated power rating for this product configuration, while the 26m³ dump body is designed for bulk material transportation.


For buyers comparing heavy-duty dump trucks, the most important factors include engine specifications, transmission, axle configuration, chassis strength, dump body dimensions, payload rating and local road regulations.


We recommend confirming these specifications before placing an order to ensure the truck matches your operating conditions.


Key Features of SHACMAN X3000 8×4 Dump Truck

1. 8×4 Heavy-Duty Drive Configuration

The 8×4 configuration is designed for heavy-duty transportation applications. The complete axle arrangement, axle ratings, suspension and tire specifications should be selected according to the intended load and road conditions.

2. 375HP Engine

This vehicle is listed with a 375HP engine configuration. The exact engine brand, model, torque, displacement and emission standard should be confirmed in the vehicle technical specification sheet.

3. 26m³ Dump Body

The 26m³ dump body is designed for bulk material transportation, including sand, gravel, soil and construction aggregates. Actual usable capacity depends on the body dimensions and loading method.

4. SHACMAN X3000 Cab

The X3000 cab configuration can be confirmed according to the vehicle specification, including cab type, sleeper arrangement, air conditioning and driver-seat options.

5. Hydraulic Dumping System

The hydraulic lifting system enables the dump body to unload materials. The lifting arrangement, cylinder specifications and unloading angle should be confirmed for the actual vehicle.

6. Configuration Options for Different Markets

Engine, gearbox, axle, tire, fuel tank, steering position and emission configuration may vary by order and destination market. Please confirm availability before ordering.


Specifications of SHACMAN X3000 8×4 375HP Dump Truck

Traction type

8×4

Drive System

LHD/(RHD is optional)

Cabin

X3000 Flat Cabin, one sleeper, Air Conditioner

Engine

Brand

WEICHAI

Model

WP12.375 E50  EuroII

Rated power

375hp

Engine displacement

11.596 liters

Gearbox

Fast 12 speeds (12JSD180T)

Clutch

Ф430 Diaphragm type

Steering

ZF technology

Axle

Front

6.5 Ton STR

Rear

16 Ton STR double reduction axle, ratio:5.73

Max. running speed (km/h)

77

Tire

12.00R20

Fuel tank

400L

Kerb weight (kg)

14200

Total mass (kg)

31000

Wheel base (mm)

1800+3600+1350

Overhang (mm) (front/rear)

1525/1955

Track (mm) (front/rear)

1939/1850

Approach / departure angle(°)

20/33

Dump body

Size

7600x2300x1500 26cbm

Thickness

Bottom 8, front 6, side 4

Lifting system

Front lifting

Overall dimensions(L*W*H)

10600x2500x3450


Applications of SHACMAN X3000 8×4 Dump Truck

Mining Operations

For transporting excavated materials and aggregates within mining sites, subject to the selected vehicle configuration and site conditions.

Quarry Operations

For moving sand, gravel, crushed stone and other quarry materials.

Construction Projects

For transporting soil, sand and construction materials at infrastructure and building sites.

Road and Infrastructure Construction

For supporting earthmoving and bulk material transportation during road and infrastructure projects.
